Kyosho: Mini-Z RWD MR04 Jaguar XJR-14

Bring classic endurance racing style indoors with the Jaguar XJR-14 No.4 LM 1991, featuring a factory-finished body with detailed markings and display-quality looks. Beneath the body, Kyosho’s fourth-generation MR-04 rear-wheel-drive chassis combines a low center of gravity with revised steering geometry for responsive handling.

A user-friendly 130-class brushed motor, full ball bearings, and geared differential deliver smooth performance. The included Syncro KT-531P 2.4GHz transmitter makes getting started simple—just install the required batteries. A wide range of optional MINI-Z parts lets you tune the car as your driving skills develop.

Required to Run

• 4x AAA alkaline batteries for the chassis
• 4x AAA alkaline or Ni-MH batteries for the transmitter

Features

• MR-04 rear-wheel-drive chassis with a low center of gravity and updated steering design
• Factory-painted Jaguar XJR-14 No.4 LM 1991 body with applied markings
• 130-class brushed motor, full ball bearings, and geared differential
• Includes Syncro KT-531P 2.4GHz pistol-grip transmitter
• Supports optional MZW711 gyro and a wide range of MINI-Z tuning parts

Specifications

• Part Number: KYO32369LE
• Chassis: MR-04W-LM
• Drivetrain: Rear-Wheel Drive
• Motor: 130-Class Brushed
• Length: 177.0mm
• Width: 79.5mm
• Height: 44.0mm
• Wheelbase: 102.0mm (3L)
• Front Tread: 67.5mm
• Rear Tread: 65.0mm
• Front Wheel Offset: Narrow +3.0mm
• Rear Wheel Offset: Wide +1.0mm
• Weight: 168g
• Radio System: Syncro KT-531P 2.4GHz
• LED Compatibility: MZW429R LED light unit cannot be installed on this body

Contents

• 1x Factory-assembled MR-04 chassis with wheels and tires
• 1x Pre-painted Jaguar XJR-14 No.4 LM 1991 body with markings
• 1x Syncro KT-531P 2.4GHz transmitter
• 1x Front tread adjustment parts set
• 1x Pinion gear set with 6T, 7T, 8T, and 9T gears
• Spare nuts
• 1x Wheel wrench
• 1x Pinion gear tool
