Traxxas: 4-Tec 2.0 VXL Chassis

Built for precision and speed, the 4-Tec 2.0 VXL chassis delivers over 70 mph performance with shaft-driven 4WD, adjustable suspension, and Velineon brushless power for ultimate on-road control.

What You’ll Need

• Standard 200mm body
• 2-3s Lipo and compatible charger
• Four AA alkaline batteries for the transmitter

Features

• Adjustable Body Mounts and Chassis
• Velineon VXL-3s Waterproof ESC and Velineon 3500Kv Brushless Motor
• Low Center of Gravity (Low CG) Chassis
• High Performance Suspension
• TQi 2.4 GHz Radio System

Specifications

• Type: On-Road Car
• Top Speed: 70+ mph
• Skill Level: 3
• Scale: 1/10
• Length: 379mm
• Width: 200mm
• Height: 62mm
• Weight: 3.18 lb
• Front Track: 196mm
• Rear Track: 200mm
• Wheelbase: 256mm
• Ground Clearance: 9mm
• Driveline: Shaft-driven AWD
• Transmission: Single-speed direct drive
• Differential Type: Sealed, hardened-steel bevel, limited slip
• Gear Pitch: 48
• Steering Servo: 2075 digital high-torque waterproof
• Radio System: TQi 2.4 GHz 2-channel with TSM
• Battery Compartment: 158 × 46 × 23 mm or 26 mm

Motor Specifications

• Name: Velineon 3500
• Motor Type: Sensorless Brushless
• Weight: 262 g (9.24 oz)
• Length: 77 mm overall, 56 mm can
• Diameter: 36 mm
• Shaft Size: 3 mm
• Connector Type: 3.5 mm Bullet

ESC Specifications

• Name: VXL-3s™ Electronic Speed Control
• ESC Type: Brushless
• Case Size: 39 × 55 × 33 mm (1.54 × 2.18 × 1.30 in)
• Weight: 90 g (3.17 oz)
• Motor Connectors: 3.5 mm Bullet
• Battery Connectors: Traxxas High-Current Connector
• Power Wire: 12-gauge Maxx® Cable

What’s In The Box

• 4-Tec 2.0 Chassis

• TQi 2.4 GHz Radio System

• Quick Start Guide
• High Quality Maintenance Tools
