Hobbywing: XRotor 20x20 4in1 45A ESC
Regular price
$74.99
Sale price
$104.00
Shipping calculated at checkout.
Important note
- Power capacitor must be installed. Every Xrotor 45amp 4-1 includes 2 power capacitors. One larger, and one smaller. The larger capacitor should be used for 5s-6s lipo, the smaller capacitor can be installed for 4s-5s lipo directly on the PCB (ESC), not by a power plug. Failure to use the included power capacitors will result in damage to your ESC.
- BL_Heli_32 ESC settings can cause damage. Default settings should be used.
- Motor KV ratings and prop size/pitch combinations recommendations.
- 4s Lipo using 5 inch props up to 2700KV
- 5s using 5 inch props, up to 2450 KV
- 6s using 5 inch props up to 1750 KV
Specifications
- SKU: 30902065
- Lipos: 3-6s Lipo
- Cont.Current: 45Ax4
- Burst Current: 60Ax4
- BEC Output: N/A
- Input wires: 14AWG-100mm
- Output Wire: No wires but solder tabs
- Connectors: XT60 (w/ Wires Soldered on)
- Weight / Size: 12g/ 40x33x5mm
